RT-SHPM 室溫原子力顯微鏡
上海伯東代理英國 NanoMagnetics RT-SHPM 室溫原子力顯微鏡, 納米尺度的磁性定量和非侵入性測量
系統參數
Imaging Modes           : SHPM, STM, AFM, MFM, EFM
Scan Size                     : 52 x 52 μm, linearised with 20 Bit resolution
                                      (Different scan sizes are optional)
Z Range                       : 4.8 μm (20 Bit resolution)
Sample Approach        : 50 mm range, 0.5 μm resolution motorised Z stage
XY Positioning             : 50 mm travel, 50 nm resolution motorised XY stage
                                       (Larger XY travel ranges are optional)
Sample Size                 : 100 x 100 x 50 mm maximum
                                       (Larger sample sizes are optional)
Video Microscopes      : Integrated Microscopes
                                      Top view 2 μm resolution
                                      Side view 10 μm resolution
                                      Adjustable white light sources
Large Area Scans         : 50 x 50 mm motorised SHPM scans for low resolution experiments
Acoustic Isolation        : Special system for acoustic and thermal isolation (optional)
Vibration Isolation       : 0.3 Hz cut-off in XYZ directions (optional)
